A dobby loom is a loom whose heald shafts are raised and lowered by a dobby: a shedding device that chooses, pick by pick, which shafts lift. Every end drawn through a shaft rises with it, so a dobby pattern repeats on no more different ends than there are shafts, but it can run for hundreds of picks. That places the dobby between cam or tappet shedding, which in ordinary looms stops at about eight shafts and eight picks to the repeat, and the Jacquard, which lifts warp ends one by one. Stäubli’s current rotary dobbies for patterned fabrics drive 16 to 24 heald frames, and its dobbies for technical fabrics up to 30, or 56 with a double head. The pattern was first pegged into a chain of wooden lags, then punched into paper cards, and is now an electronic file. Dobbies weave small geometric figures: diamonds and diapers on pointed drafts, honeycombs, piqués, bordered towels and dhoti borders.
Last verified: 11 October 2026. Mechanisms are from two public-domain textbooks (Roberts, 1912; Watson, 1921) and Istanbul Technical University’s weaving lecture notes; machine sizes are from the makers’ own pages; Indian handloom figures are from the Ministry of Textiles. Sources are listed at the end.
Dobby loom at a glance
| Question | Short answer |
|---|---|
| What does a dobby move? | Heald shafts (frames). Each carries every end drawn into it, so the design comes from the draft and the lifting plan together. |
| How many shafts? | 16 to 24 lifting units on Stäubli’s rotary dobbies for patterned fabrics; up to 28 on its S2688 S (56 in the double-head version) and 30 on its S4080. In 1912, 16 to 48, with 16, 24 and 36 most common. |
| How many picks per repeat? | Practically unlimited: one row of pegs, card line or program line per pick. |
| Where is the pattern held? | Pegged wooden lags on a chain, then punched paper cards, now an electronic controller. |
| Positive or negative? | Negative dobbies lift the shafts and springs return them; positive dobbies drive them both ways. |
| Open or closed shed? | Double-lift dobbies give an open shed; single-lift dobbies close the shed after every pick. |
| How fast? | Single-lift dobbies are limited to 160 to 180 rpm; rotary dobbies allow weaving machines up to 1,000 to 1,500 rpm. |
| What does it weave? | Diamonds and diapers, honeycombs, piqués and welts, bordered towels and shawls, dhoti borders. |
| When is a Jacquard needed? | When the figure needs more different ends than the dobby has shafts. |
| How common on handlooms? | In India’s 2019–20 handloom census, 67.3% of pit looms and 32.6% of frame looms had a dobby or a Jacquard. |
What is a dobby loom?
Looms are classed by how they form the shed, the opening between raised and lowered warp ends through which the weft passes. Thomas Roberts, head of weaving at the Holmfirth and Dewsbury technical institutes, divided power looms into tappet, dobby and Jacquard looms, and wrote that the dobby loom “occupies a medium position between the tappet and the jacquard loom” (Tappet and Dobby Looms, 1912, pp. 1 and 75). The three systems are introduced on the site’s page on types of shedding mechanism.
The limits are set by shafts and picks. William Watson, of the Royal Technical College in Glasgow, gave eight shafts and eight picks to the repeat as the general limit of ordinary tappet shedding, and each new interlacing needs a different tappet. A dobby, he wrote, works 8 to 24 shafts, sometimes more, with 16 to 20 the most common, and “the number of picks to the repeat is only limited by the amount of space and the method of support that are available for the lags” (Textile Design and Colour, second edition, 1921, pp. 20–21). Stäubli’s current cam motions have 8 or 10 lifting units. A Jacquard has no shafts at all: it lifts ends individually through hooks and harness cords (see how a Jacquard machine works).
“Dobby” names the shedding device, and a dobby loom is a loom fitted with one; “dobby machine” is used for either. On a modern weaving machine the dobby is a separate unit mounted on the machine: Stäubli’s S3000 can be installed in a low or high position on water-jet, air-jet and rapier machines, and its S2688 on the right or the left. The weft is carried by the loom’s own insertion system, shuttle, rapier, projectile or jet, which the dobby does not change (see shuttle and shuttleless looms compared).

How a dobby works: the dobby loom mechanism
Every dobby has three parts. A drive mechanism takes motion from the weaving machine; a selection mechanism reads the pattern for the next pick; a lifting mechanism moves the heald shafts that were selected (Istanbul Technical University, TEK332E Weaving Technology II, “Shedding: Dobbies”, slide 6).
On a mechanical dobby the pattern is a chain of wooden bars called lags, with a row of holes for each pick and a hole in the row for each shaft. A peg in the hole lifts that shaft; an empty hole leaves it down; a run of pegs on successive picks holds the shaft up for as many picks (Roberts, pp. 89–91). Some dobbies used pulleys and bushes on the chain instead, a pulley to lift and a bush to lower (Roberts, pp. 76–78). India standardised the wooden parts: IS 3496 (1966) covers dobby lags with two lines of peg holes and their pegs, and noted that metal and plastic lags were not then made in the country, and IS 4416 (1967) covers the barrels those lags run on. Roberts describes the same two rows on the double-lift lever dobby: the front row is pegged for the odd picks and the back row for the even picks (p. 88).

Negative and positive dobbies
In negative dobby shedding the dobby lifts the shafts and a spring reversing motion lowers them; in positive shedding the dobby both raises and lowers them (ITU, slide 3). Roberts found negative dobbies unsuitable for heavy goods, which need more power on the shafts than the springs give unless a very powerful reversing motion is fitted, and worst on backed and double cloths, where a shed with few shafts up follows one with many: the springs then oppose the loom as the shed opens and push it as the shed closes, “yielding very unsteady running” (pp. 87–88). The lecture notes record the trend away from negative dobbies towards electronically controlled positive ones, which can run at very high speeds.
Single-lift and double-lift; open and closed shed
A single-lift dobby, the oldest kind, completes its whole cycle every pick: the shed closes after each weft and the pick is beaten up in a centre-closed shed, which limits these dobbies to 160 to 180 rpm. A double-lift dobby spreads its cycle over two picks, so most of its motions run at half the loom’s speed, while a shed still opens every pick; shafts that stay up stay up, which gives an open shed and suits high speeds. All new dobbies are double-lift (ITU, slides 4–5). Roberts made the same point in 1912: the open shed “facilitates high speeds”, while a centre closed-shed dobby moves the warp more, needs more power and cannot run as fast (pp. 78 and 93). Both are still made: Stäubli’s S2688 is an open-shed rotary dobby, and its S4080 a closed-shed dobby for the felts of papermaking machines.
Mechanical dobbies: Keighley, Hattersley and wheel dobbies
Roberts divided the mechanical dobbies of his day into wheel dobbies, typified by the Hollingworth and Knowles dobby of the Dobcross loom makers, and lever dobbies, typified by the Keighley dobby, “the invention of Messrs Hattersley and Sons” (p. 75). Lever dobbies were “far more numerous”. In the simple double-lift negative lever dobby, two lifting knives pull draw hooks that turn the jacks and lift the shafts; a reversing motion, usually springs, pulls them back. The Hattersley double-action open-shed dobby was positive: hooks selected by needles and tumblers, according to the pegs, worked a baulk lever and jack that both lifted and lowered each shaft (pp. 87–91). According to the ITU notes, the mass of its cast-iron hooks was the obstacle to speed: a modified version with much lighter hooks reached 500 rpm on shuttleless machines (slide 24).
The rotary dobby
The rotary dobby takes its name from deriving the shafts’ up-and-down motion from rotating parts instead of reciprocating knives (ITU, slides 25–32). A modulator turns the loom’s steady rotation into an intermittent one: the dobby’s main shaft turns through 180 degrees, then pauses briefly so the next selection can be made. Each heald frame has its own cam unit, only 12 mm wide: a heart-shaped crank disc enclosing an eccentric on ball bearings, and a key, the only part the pattern controls. When the key couples the eccentric to the main shaft, the next half-turn moves the frame up or down; otherwise the frame stays put. The notes give weaving machine speeds of up to 1,000 to 1,500 rpm with a rotary dobby. Stäubli’s Swiss patents for a wedge or key clutch in a dobby, coupling an eccentric ring to the drive shaft, were filed on 29 May 1970 (CH512605A, published 1971; CH522057A, published 1972).
Electronic dobbies
An electronic dobby keeps the lifting mechanism and replaces the lags and cards with electromagnets. In the Fimtextile RD 3000 shown in the ITU notes, an electromagnetic control unit does the selecting, and the cam units and jacks do the lifting (slide 33). Stäubli describes its S3000, S3200 and S2600 rotary dobbies as electronically controlled; the S2600 can take its pattern from Stäubli’s own control unit, an integral one, or the weaving machine’s electronics. Changing a pattern then means loading a new file instead of pegging a new chain. Even with pegged chains, Watson found it “convenient and economical” to use a dobby for short experimental lengths of weaves a tappet could make (p. 21).
Dobby design: the draft, the lifting plan and the drawing-in plan
A dobby design is written as two plans. Watson defines them: “A draft indicates the order in which the warp threads are drawn through the eyes or mails of the healds”, and “a weaving or pegging plan indicates the order in which the healds rise and fall. The weave or design results from the combination of the draft and the weaving or pegging plan” (p. 20). The draft is also called the drawing-in plan; the pegging plan, named after the pegged lags, is also called the lifting plan or peg plan. On design paper the draft has a column per end and a row per shaft; the lifting plan a column per shaft and a row per pick.
With a straight draft (end 1 on shaft 1, end 2 on shaft 2, and so on) the lifting plan is the design itself, and the design can repeat on no more ends than there are shafts (Watson, pp. 21–23). Other drafts put several ends of the repeat that interlace alike on one shaft, so the repeat can be wider than the number of shafts: Watson gives a 22-end interlacing twill drafted on 16 shafts (p. 61). Roberts also describes using twice the number of shafts for cloths with many ends per inch, to share the strain over more jacks (p. 98). The site’s page on drafting plans sets out the standard kinds of draft.

Worked example: an 8-shaft diamond on a pointed draft
This is Watson’s diamond design S, T and U in his Fig. 54 (pp. 55–56), redrawn and checked here cell by cell. It shows in one small repeat why a dobby is used: the design needs 8 shafts and 14 picks, and 14 picks is beyond the 8-pick limit of ordinary tappets.
- Drawing-in plan. A pointed draft on 8 shafts: ends 1 to 8 go on shafts 1 to 8, then ends 9 to 14 come back down on shafts 7 to 2. The repeat is 14 ends. Shafts 1 and 8, where the draft turns, carry one end each; shafts 2 to 7 carry two. Watson notes that pointed drafts are frequently made to turn this way, the turning shafts needing “half as many mails as the centre healds”; turning on the same shaft each time instead keeps the number of ends equal on every shaft.
- Lifting plan. An 8-end twill that lifts three shafts, leaves two down, lifts one and leaves two down (3, 2, 1, 2), moving one shaft each pick. It runs forward for picks 1 to 8 and back for picks 9 to 14, in the same order as the draft, so the repeat is 14 picks. On pick 1 shafts 1, 2, 5 and 8 lift.
- Design. An end is up on a pick when its shaft is lifted. On pick 1 shaft 1 lifts end 1, shaft 2 lifts ends 2 and 14, shaft 5 lifts ends 5 and 11, and shaft 8 lifts end 8: six ends of 14. The result is a diamond centred on end 8 and pick 8.
- Why the pointed draft saves shafts. In the design, ends 2 to 7 interlace exactly like ends 14 to 9. A straight draft would give each of the 14 ends its own shaft; the pointed draft puts each identical pair on one shaft, so 8 shafts do the work of 14.
| Shaft | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8 | ■ | |||||||||||||
| 7 | ■ | ■ | ||||||||||||
| 6 | ■ | ■ | ||||||||||||
| 5 | ■ | ■ | ||||||||||||
| 4 | ■ | ■ | ||||||||||||
| 3 | ■ | ■ | ||||||||||||
| 2 | ■ | ■ | ||||||||||||
| 1 | ■ |
| Pick | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | Shafts up |
|---|---|---|---|---|---|---|---|---|---|
| 14 | ■ | ■ | ■ | ■ | 1, 2, 3, 6 | ||||
| 13 | ■ | ■ | ■ | ■ | 2, 3, 4, 7 | ||||
| 12 | ■ | ■ | ■ | ■ | 3, 4, 5, 8 | ||||
| 11 | ■ | ■ | ■ | ■ | 1, 4, 5, 6 | ||||
| 10 | ■ | ■ | ■ | ■ | 2, 5, 6, 7 | ||||
| 9 | ■ | ■ | ■ | ■ | 3, 6, 7, 8 | ||||
| 8 | ■ | ■ | ■ | ■ | 1, 4, 7, 8 | ||||
| 7 | ■ | ■ | ■ | ■ | 3, 6, 7, 8 | ||||
| 6 | ■ | ■ | ■ | ■ | 2, 5, 6, 7 | ||||
| 5 | ■ | ■ | ■ | ■ | 1, 4, 5, 6 | ||||
| 4 | ■ | ■ | ■ | ■ | 3, 4, 5, 8 | ||||
| 3 | ■ | ■ | ■ | ■ | 2, 3, 4, 7 | ||||
| 2 | ■ | ■ | ■ | ■ | 1, 2, 3, 6 | ||||
| 1 | ■ | ■ | ■ | ■ | 1, 2, 5, 8 |
| Pick | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | Ends up |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 13 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 8 | ||||||
| 12 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 11 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 10 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 8 | ||||||
| 9 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 8 | ■ | ■ | ■ | ■ | ■ | ■ | 6 | ||||||||
| 7 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 6 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 8 | ||||||
| 5 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 4 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 3 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 8 | ||||||
| 2 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | 7 | |||||||
| 1 | ■ | ■ | ■ | ■ | ■ | ■ | 6 |
The three plans above are one repeat each. Read them together: find a pick’s row in the lifting plan, note the shafts marked, then mark in the design every end the drawing-in plan puts on those shafts. Weaving the cloth needs only the first two; the third is what they produce. The same lifting plan with a straight draft on 8 shafts would give a zig-zag twill running up the cloth, not a diamond.
Two more things can be read from the plans. Four of the eight shafts rise on every pick, lifting six to eight of the 14 ends, so successive sheds are evenly loaded, unlike the backed and double cloths Roberts found hard on negative dobbies. And reading ■ as warp up, the longest warp float is five picks, at the centre of the diamond and where the draft turns; the longest weft float is three ends.
Weaves and fabrics made on a dobby loom
A dobby is used when a weave needs more shafts or more picks than tappets give, or when the pattern changes too often to cut new tappets. The textbook cases:
- Diamond and diaper designs on pointed drafts, like the worked example (Watson, pp. 55–62).
- Waved and zig-zag twills. Horizontal zig-zags can be woven on a few shafts with twill tappets, but vertical zig-zags “mostly require a dobby shedding motion, because of the comparatively large number of picks” (Watson, p. 51).
- Honeycomb. Ordinary honeycombs are woven on pointed drafts and are used for towels, bedcovers and quilts (Watson, p. 78). The site’s honeycomb weave page works the drafts.
- Piqués and welts. Watson gives the waved piqué with a draft and a pegging plan, that is, for a dobby (p. 99).
- Bordered cloths. A cross-border dobby, with one pattern cylinder for the ground and another for the borders, wove towels, shawls and table covers (Roberts, p. 94).
- Dhoti borders. For dhotis, cloths worn in India, Watson records that most of the figured border effects were woven in extra warp “by means of large dobbies with connections to the dobby jacks similar to a jacquard harness in place of healds” (appendix on standard fabrics, p. 394).
- Fancy suitings and dress goods. Roberts lists fancy coatings, trouserings, fancy dress goods, mantle cloths, cap tweeds, mauds and rugs as dobby-loom cloths (p. 2).
Not every small weave needs a dobby. Watson notes that the standard huckaback towelling weaves were usually woven with tappets, on a draft arranged so that the same healds could also weave plain cloth (p. 82).

Dobby vs Jacquard loom
The difference is what gets lifted. A dobby lifts shafts, so all the ends on one shaft weave alike and the figure is limited to as many different ends as there are shafts. A Jacquard lifts ends through hooks and harness cords, so the figure can be as wide as the hooks used. Watson puts the boundary simply: a Jacquard “is necessary in weaving designs that are beyond the scope of dobby shedding”, though it was also used for dobby designs in pattern ranges and short runs (p. 204). Roberts’s Jacquard cloths are fancy vestings, figured dress goods, tapestries, plushes and carpets, since “the number of threads which a design may occupy is practically unlimited” (p. 2). The site’s Jacquard page compares tappet, dobby and Jacquard shedding side by side.
Dobby makers and current sizes
Each figure below is as the maker states it. Stäubli gives its dobby sizes in lifting units and in pitch, the spacing of those units; in a rotary dobby each heald frame is controlled by its own cam unit (ITU, slide 37). Stäubli’s pages give no rated speeds.
| Machine | What it is | Size, as stated |
|---|---|---|
| Stäubli S3000 | Electronically controlled rotary dobby for patterned fabrics on water-jet, air-jet and rapier machines; low or high position | Housing of 16 or 20 lifting units |
| Stäubli S3200 | The same for air-jet and rapier machines; low position | 16, 20 or 24 |
| Stäubli S2600 (S2665, S2675) | Electronically controlled positive rotary dobby for projectile machines | 18 lifting units, 12 mm pitch |
| Stäubli S2688 | Electronically controlled open-shed rotary dobby for technical fabrics, notably forming fabrics; S model for high speed, RS for high warp tension | S: up to 28 lifting units at 20 mm pitch, or 56 at 10 mm in the double-head version. RS: up to 20 |
| Stäubli S4080 | Electronically controlled closed-shed dobby for wet felts, seam felts and dryer felts for papermaking machines | Up to 24 lifting units at 20 mm pitch, or 30 at 16 mm |
| Wanli WL450 rapier loom | Loom sold with an electronic dobby or an electronic Jacquard | Electronic dobby of 16 to 20 shafts; maximum speed 300 to 500 rpm |
| Fimtextile RD 3000 | Rotary dobby with electromagnetic selection, as shown in the ITU lecture notes | No figure read from the maker |
The pitch figures show the trade-off inside one housing. On the S4080, 24 units at 20 mm and 30 units at 16 mm both take 480 mm; on the S2688, 28 at 20 mm and 56 at 10 mm both take 560 mm. More shafts in the same space means heald frames set closer together. The ITU notes put the usual range of dobbies at 12, 16, 20, 24, 28 and up to 30 heald frames (slide 2). For comparison, Stäubli’s S1600 and S1700 cam motions have 8 or 10 lifting units. Stäubli says it has made frame weaving machinery since 1892.
Dobby loom speed and output: a worked example
Loom speed is quoted in rpm, which on a conventional single-phase loom is picks per minute. The dobby sets a ceiling on it. The ITU notes give 160 to 180 rpm as the limit of single-lift dobbies, 500 rpm for the lightened Hattersley dobby on shuttleless machines, and up to 1,000 to 1,500 rpm for weaving machines with rotary dobbies. A current maker’s figure for a whole dobby loom: Wanli gives its WL450 rapier loom, sold with an electronic dobby of 16 to 20 shafts, a maximum speed of 300 to 500 rpm, and lists a “high speed dobby rapier loom” at 250 to 500 rpm.
Take the 8-shaft diamond above as a cloth of 60 picks per inch and 55 inches wide, and run it for an 8-hour shift at 85% efficiency. The efficiency is an assumption for the example, not a maker’s figure; real efficiency depends on the yarn, the pattern and the mill. Output in metres per hour = rpm × 60 × efficiency ÷ picks per inch × 0.0254.
| Same cloth, two dobby looms | Single-lift dobby limit | Dobby rapier loom, maker’s maximum |
|---|---|---|
| Speed | 180 rpm | 500 rpm |
| Picks inserted per hour (85%) | 9,180 | 25,500 |
| Cloth per hour | 3.89 m | 10.80 m |
| Cloth per 8-hour shift | 31.09 m | 86.36 m |
| Area per hour, 55 inches wide | 5.43 m² | 15.08 m² |
| Check it | Loom production calculator at 180 rpm | Loom production calculator at 500 rpm |
The arithmetic shows the price of picks: at 60 picks per inch the faster loom makes 86 metres a shift, and the same loom on a 120-pick cloth would make half that. The site’s weaving calculations page works the loom production formula through one fabric with the other weaving formulas.

Dobbies on Indian handlooms
Dobbies and Jacquards are common on Indian handlooms. The Fourth All India Handloom Census 2019–20 of the Ministry of Textiles counted 28.2 lakh handlooms. Of these, 8.15 lakh were pit looms with a dobby or Jacquard and 2.91 lakh frame looms with one: 67.3% of all pit looms and 32.6% of all frame looms (p. 53). The census counts dobby and Jacquard together, so the split between them is not known. Together they are on about 11.1 lakh looms, 39% of the total. It defines a pit loom with dobby or Jacquard as a fly-shuttle pit loom fitted with one (pp. 29–30).
Dobbies are also part of government support. The Hathkargha Samvardhan Sahayata scheme was announced at the second National Handloom Day in Varanasi on 7 August 2016 to give weavers technology upgrades with the Government of India paying 90% of the cost; its guidelines list a dobby among the items, beside Jacquards, take-up and let-off motions and frame looms (HSS guidelines). For design, DigiBunai, open-source software from the Digital India Corporation, has a dobby module alongside its Jacquard tools (DigiBunai). The wooden lags and barrels of the mechanical dobby have had their own Indian Standards since the 1960s, as described above.
Common dobby faults and their causes
Because a dobby has more parts than a cam motion, it is more liable to cause fabric faults (ITU, slide 2). Roberts’s chapter on dobby mechanism, written from years of mill practice, lists what goes wrong and why.
| Fault | What it looks like | Causes recorded |
|---|---|---|
| Jack-missing | A shaft stays up when it should be down, or the reverse, or moves only part of its stroke; a half-formed shed gives “stitching or scobbing” and can throw the shuttle out | Strained lags from the chain gathering on the cylinder; broken pulleys; lags not evenly spaced, so they ride on the cylinder; sticking needles; bruised, broken, short or missing pegs; hooks slipping off the knife; lock-knife or lag cylinder out of time; worn parts (Roberts, pp. 85–88) |
| Cracks from the selvedge | Weft-way lines running in from the selvedge and fading towards the centre, plainest with contrasting warp and weft | A heald shaft not hanging level, one side higher than the other (Roberts, p. 96) |
| Badly formed selvedge | Slack ends near the edge stop the weft drawing up tight | A shaft not lifted to its proper level (Roberts, pp. 96–97) |
| Weft staplings | Small loops of weft drawn in at the beat-up, or broken hanging ends | A shed that is not clear, on cloths such as cords and dense settings (Roberts, p. 97) |
| Oil stains on the warp | Dark marks that are hard to remove, and if left may tender the yarn in bleaching | Dirty oil dripping from moving parts above the warp; a tray beneath them is essential (ITU, slide 14) |
Roberts’s remedy for a jack-missing on one shaft is to trace the floating thread back to the healds, find which shaft it is drawn on, and overhaul the parts that control that shaft. He also notes the limits of shed depth. In dobbies with 24 or 36 jacks the first and last heald shafts are 10 to 15 inches apart, and the back shafts must move further to give a clean, sloping shed, so the back shaft’s stroke limits the depth of shed and the size of shuttle (p. 97).
History: from the draw boy to the electronic dobby
Before dobbies, a figure beyond the reach of treadles was woven on the drawloom, with a second worker, the draw boy, pulling the figure cords (see treadles, shafts and the drawloom). No primary source read for this page dates the first dobby, so the table starts where the record does.
| Date | What happened | Source |
|---|---|---|
| 1892 to 1893 | Schelling and Stäubli founded in Horgen, Switzerland, in 1892; its first dobby, designed and built in house, introduced in 1893 | Stäubli release, reprinted by Textile World (2017) |
| 1900 | Stäubli introduces what it calls the world’s first paper-card dobby | The same release |
| 1912 | Dobbies of 16 to 48 shafts in use; wheel dobbies (Hollingworth and Knowles) and lever dobbies (the Keighley dobby, invented by Hattersley and Sons); open-shed and centre closed-shed types | Roberts, Tappet and Dobby Looms |
| 1921 | Dobbies of 8 to 24 shafts, sometimes more, with 16 to 20 most common | Watson, Textile Design and Colour, second edition |
| 1966 to 1967 | Indian Standards for wooden dobby lags and pegs (IS 3496) and dobby barrels (IS 4416) | Indian Standards, scanned copies on the Internet Archive |
| 1969 | Stäubli buys Trumpelt, a German maker of heavy dobbies | Stäubli release (2017) |
| 1970 | Stäubli files Swiss patents for a key clutch coupling a dobby’s eccentric to its drive shaft | CH512605A; CH522057A |
| Today | Electronically controlled rotary dobbies of 16 to 24 lifting units for patterned fabrics, and up to 30 for technical fabrics, or 56 with a double head; ITU lecture notes give machine speeds up to 1,000 to 1,500 rpm | Stäubli product pages; ITU |
| 2019 to 2020 | 67.3% of India’s pit handlooms and 32.6% of its frame handlooms have a dobby or Jacquard | Fourth All India Handloom Census |
Questions about dobby looms
What is a dobby loom?
A loom fitted with a dobby, a device that selects which heald shafts rise on each pick. It weaves patterns too complex for cams but small enough to fit on the shafts available, 16 to 24 on Stäubli’s current rotary dobbies, and up to 30 on its dobbies for technical fabrics, or 56 with a double head. Roberts placed it midway between the tappet loom and the Jacquard.
How does a dobby loom work?
The dobby is driven from the loom, reads one line of the pattern each pick (a pegged lag, a punched card or an electronic signal), and connects the selected shafts to its lifting mechanism. In the rotary dobby described in the ITU notes, each shaft has a cam unit only 12 mm wide whose key either couples it to the main shaft for the next half-turn or leaves it idle.
What is the difference between a dobby and a Jacquard loom?
A dobby lifts shafts, so every end on a shaft moves together and the figure is limited by the number of shafts. A Jacquard lifts ends individually through hooks, so the figure can be thousands of ends wide. Large figures such as tapestries and carpets need a Jacquard; diamonds, honeycombs and piqués do not.
How many shafts can a dobby control?
Stäubli’s rotary dobbies for patterned fabrics come with 16 to 24 lifting units (16, 18, 20 or 24, depending on the model); its S2688 takes up to 28, or 56 in a double-head version, and its S4080 up to 30. The ITU notes give 12 to 30 frames as the usual range. In 1912 Roberts recorded dobbies of up to 48 shafts.
What fabrics are made on a dobby loom?
Small geometric weaves: diamonds and diapers, zig-zag twills, honeycomb towelling, piqués and welts, bordered towels and shawls, and figured dhoti borders. Roberts’s 1912 list adds fancy coatings, trouserings, dress goods and rugs.
What is an electronic dobby?
A dobby whose selection is made by electromagnets under program control instead of by pegged lags or punched cards. The lifting is still mechanical; in the machines described on this page it is done by rotary cam units. A new pattern is a new file, not a new chain.
How this page is kept
Last verified: 11 October 2026. Every source was read on that date.
- Mechanism, faults and the fabrics of 1912: Thomas Roberts, Tappet and Dobby Looms: Their Mechanism and Management (Emmott, Manchester, 1912; 1920 reprint).
- Drafts, pegging plans, the diamond example and dobby weaves: William Watson, Textile Design and Colour, second edition (Longmans, Green, 1921), pp. 20–23, 51, 55–62, 78, 82, 99, 204, 394.
- Dobby types, speeds and the rotary dobby: E. Önder and Ö. B. Berkalp, “Shedding: Dobbies”, TEK332E Weaving Technology II, Istanbul Technical University.
- Current machines: Stäubli’s frame weaving product pages, read from archived copies because the live pages refuse automated requests; Stäubli’s 1970 patents on Google Patents; Wanli’s rapier loom pages. Stäubli’s company history is its own, as reprinted by Textile World.
- India: the Fourth All India Handloom Census 2019–20 (Ministry of Textiles); the Hathkargha Samvardhan Sahayata guidelines; IS 3496 (1966) and IS 4416 (1967); DigiBunai.
- The worked diamond is Watson’s, recomputed cell by cell; the production example uses the site’s loom production calculator as it stood on 11 October 2026, with an assumed 85% efficiency.
Change log. 11 October 2026: rewritten in full. Removed: three unsourced “case studies” (an Italian mill, a French factory and a multinational, with gains of 15% to 30%); unsourced claims about energy saving, IoT and predictive maintenance; a section on “future trends in Jacquard weaving technology”; a line promoting this site; two unrelated images. Corrected: a dobby does not control warp threads individually or make “non-repetitive” designs; it lifts shafts, so its designs repeat on no more different ends than it has shafts.
Found an error? Please tell us through the contact page, naming the section and the source that disagrees.
